i-HP Industrial inverter air/water heat pumps with axial fans
34
The accessibility to the electrical box is from the front enclosure panel (with closed unit)
The electric box is opened (i-HP 0125 / i-HP 0135 / i-HP 0250F / i-HP 0250)
If the units are equipped with GI module (which is standard for “LT” injection models), there are also other components
installed in an additional plate at the bottom left side of the electric box
On-board terminal block and
user’s terminal block
Driver board (one
for each inverter
compressor
Disconnecting switch
with door lock
To Next Page
