MAXA i-HP 0270 - ELECTRIC PANEL

i-HP Industrial inverter air/water heat pumps with axial fans
33
23 ELECTRIC PANEL
N.B. The number of indicated components can vary depending on the model.
The representation of the units is indicative and useful to present the main components and can therefore vary from the
purchased one.
The front panel is closed
The front panel is open at 180°
Disconnecting switch
with door lock for
electric box
Master controller
protection cover
Handle for front
panel opening
Heat sinks of driver
boards
