MAXA R407C - Page 21

CD 30 ÷ 520
21
8.1. Heating and cooling capacity mod. 30 Kw
Cooling capacity Power input
Outlet water temperature Outlet water temperature
Ambient temp. °C
5ć 7ć 9ć 12ć 5ć 7ć 9ć 12ć
25 31.2 33.1 34.4 35.5 8.6 8.8 9 9.3
28 30.9 32.4 33.9 35.2 8.8 8.9 9.1 9.4
30 29.9 31.5 33 34.7 9.2 9.3 9.5 9.8
32 29.7 31.2 32.7 34.2 9.4 9.5 9.7 10
35 28.5 30 31.8 33 9.7 10 10.3 10.5
38 27.6 29.1 30.6 31.8 10.3 10.5 10.8 10.8
40 27 28.2 29.7 31.2 10.6 10.8 11.1 11.1
Cooling capacity adjustment with digital control unit
Temperature of plate heat exchanger
Temperature of plate heat exchanger
Heating capacity adjustment with digital control unit
