LED display
– Field of view completely uncovered:
The left LED flickers, the two LEDs to the right of it are off.
Example A
– Field of view partially covered by the material:
The left LED is lit, the middle LED flickers and the right LED is
off.
Example B
– Field of view completely covered by the material:
The two left LEDs are lit while the right LED flickers.
Example C
Figure 6.1: DSE-15 sensor
flickers
off
off lit
flickers
off
lit
lit
flickers
Example A Example B Example C
