TECHNICAL DATA9 - 1
DSE-15 www.maxcess.euMI 1094 1
9 TECHNICAL DATA
General information Dimensions
figure 3.1, page 3-2
Weight
100g (with cable and plug)
Protection class
IP 65
Ambient conditions
Ambient temperature: 5°C ... 60°C
Relative humidity: up to 90%, non-condensing
Operating altitude max. 3000m above sea level
Materials used
Housing: Plastic, VISTAL®
Protector: PMMA (polymethylmethacrylate), glued
A data sheet can be requested on this material
(EK0471).
Properties Light source
LED
visible red light
Wavelength
λ = 632nm ± 6nm
Δλ = 20nm
Sensor field of view
10mm
Linearity
5% max. error
in the proportional band of 6mm
Web plane change
1% max. error
Temperature error
2% (at 10°C .. 50°C)
