II. Main Technical Parameters for Forklift Truck
Forklift Truck
Lifting Capacity
Parameter
5t 6t 7t 8t 10t
Rated Load-lifting Capacity kg 5000 6000 7000 8000 10000
Load Center Distance 600
Max Lifting Height (Standard) B 3000
Free Lifting Height (Standard) E
mm
195 200 205 200 210
Mast Tip Angle Y/Y (º)/( º) 6/12
Min Turning Radius W 3250 3300 3370 3700 3900
Min Right Angle Aisle Width X 2960 3000 3040 3310 3540
Min Off-ground Clearance G 200 250 245
Wheelbase L 2250 2500 2800
Tread Front/Rear S/T 1470/1700 1600/1700
Clearance Front/Rear K/M 590/600 590/675 590/740 700/740 718/740
Whole Length H 4660 4735 4800 5160 5480
Entire Length Q 1995 2165 2245
Mast C
mm
2500 2625 2700 2850 Whole
Height
Overhead Guard P mm 2450 2585
Height at Rise of Fork (with Cargo
Stop Frame) A
4420 4330
Length J 1220
Fork
Width×Thickness F 150×55 150×60 150×65 170×70 175×80
Fork Adjusting Range (Outer
Side of Fork) R
mm
300-1700 340-1944 410-2140
Forklift Truck Dead Weight 8080 8740 9450 11660 12610
Full Load Front/Rear 11660/1320 13050/1590 14570/1780 17000/1950 20380/2130 Axle
Load
No-Load Front/Rear
kg
4010/3970 3880/4760 3860/5490 4840/6120 5700/6810
Front 4 8.25-15-14PR 9.00-20-14PR
Tyre
Rear 2 8.25-15-14PR 9.00-20-14PR
Batte4ry Voltage/Capacity V/Ah 24/80
