maximal FD80T - Steering System

5-10t Internal Combustion Counterbalance Forklift Truck Operation & Maintenance Manual
-
82
-
6. Steering System (Refer to Table 6-1 for main parameters)
Table 6-1
Parameter/Structure Parameter
Truck Tonnage
Name of Item
5-7t 8t 10t
Type of Steering System
Rear-axle Steering with Power Steering
Diameter of Steering Wheel ㎜
360
Model
BZZ Portfolio Full Hydraulic Steering Unit
Displacement ml/min
280
Steering Unit
Rated Pressure MPa
16
Type
Cross Type and Double-Action Type
Cylinder Diameter/Rod Diameter ㎜
Φ115/Φ85
Steering
Cylinder
Stroke ㎜
2×216 2×260
Set Pressure MPa
12.3
Bypass Valve
Rated Flow Rate 1/min
25 27
Type Central Supporting Shaft Supported and Cross
Cylinder Type
Steering Angle Outer Wheel/Inner Wheel
79°/50°
Rear-Wheel Tread ㎜
1700
Steering Axle
Steering Knuckle King Pin Spacing ㎜
1500
Slewing Diameter of Universal Joint Assembly ㎜
Φ42
Tyre
8.25-15-14PR 9.00-20-14PR
Wheel Rim
6.50-15 7.0-20
Wheel
Air Pressure MPa
830 760
