7. Hydraulic System
Refer to Table 7-1 for main technical parameters.
Table 7-1
5-7t 8-10t
Truck Tonnage
Brake Type
Item
Power Brake Vacuum Power Brake Power Brake
Drive Type Transmission Power Output
Rated Pressure 25MPa
Equipped with
Japan 6BG1
Perkins 1104D
CBHY-G36/F3.5-ATΦ
Duplicate Pump
CBHY-G36/F3.5-ATΦ
Duplicate Pump
Equipped
with
Chaochai
6102BG
CBHY-G32/F3.5-ATΦ
Duplicate Pump
CBKa-G432-ATΦR
GBHY-G32/F3.5-ATΦ
Duplicate Pump
Front Gear
Pump
Drawing
No
Equipped with
Mitsubishi
S6S-T
CBHY-G25/F3.5-ATΦ
Equipped with
Japan
6BG1
Perkins 1104D
CBKa-G436-ATΦL CBKa-G436-ATΦL
Equipped with
Chaochai
6102BG
CBKa-G432-ATΦL CBKa-G432-ATΦL CBKa-G432-ATΦL
Main Oil
Pump
Rear Gear
Pump
Drawing
No
Equipped with
Mitsubishi
S6S-T
CBKa-G432-ATΦL
Type
Double Valve Stem Slide Type (with Safety Valve, Bypass Valve, and Tilt
Auto-locking Valve)
Set Pressure 20MPa
2-Plate Valve CDB-F20-02 CDB-F20-02
3-Plate Valve CDB-F20-03a CDB-F20-03a
Multi-w
ay Valve
Drawing
No
4-Plate Valve CDB-F20-04b CDB-F20-04b
