Maxon BMR-CS Series - OPENING THE RETENTION RAMP - STEEL PLATFORM

13
OPENING THE RETENTION RAMP - STEEL
PLATFORM
To release retention ramp,
rotate locks in direction of
arrows (FIG. 13-1) and unfold
ramp to the ground (FIG. 13-2).
RAMP IN RETENTION
POSITION
FIG. 13-1
LOCK
LOCK
FIG. 13-2
RAMP POSITION
