STEP 2 - WELD LIFTGATE TO VEHICLE - Continued
WELD TO VEHICLE FRAME - WALK RAMP
(RH SIDE SHOWN)
FIG. 27-1
VEHICLE FRAME
(TYPICAL TRUCK FRAME SHOWN)
MOUNTING PLATE
MAIN FRAME
2” LG. 4 PLACES
(TYPICAL - RH & LH
MOUNTING PLATES)
1/4”
BED LEVEL
24-1/2”
