516532 B PUBLICATION DATE 1 JUN 2007.DOC PROGRAMMING MANUAL 5
3.2. SERVICE - SET-UP MODE
• Turn the Service key to switch from RUN mode to SERVICE - SET-UP mode.
• In Service – SET-UP mode, the Main Menu Screen appears.
• In the Main Menu we can select the Category Based Menu’s.
) Each Menu is explained in detail in the following chapters.
T CYCLE & STATUS Menu :
Stop & Advance a wash cycle.
Status information of current cycle.
T PRICE Menu :
General Set-up of Pricing related functions.
Set-up machine as Single Price, Temperature Based (Individual) Price or Upgradeable
Pricing.
Set-up wash cycle Normal Price and Special Prices.
T WASH CYCLE Menu :
To Edit a wash program step by step, wash function by function.
T SERVICE Menu :
Cycle Credit.
Run Diagnostic program
List with Diagnostic codes and Help codes and a List with Statistics.
Toolbox Functions :
- View electric Input signals.
- Turn On/Off power supply Motor frequency inverter.
- Select-Reset Cycle counter.
T INITIALIZATION Menu :
Select the wash computer Language.
Select Hot Water Heater Temperature (hot water supply).
Select Maximum Fill time value.
Select Level Overfill Detection value.
T CONFIGURATION Menu :
Select wash Machine Type.
Loading default Factory Settings for resetting wash computer.
Adjusting the visual Brightness angle of the display.
Loading the frequency Inverter Parameters.
Erasing all the programmed Wash Programs (reset Wash Program EEPROM memory).
Loading the Standard Wash Programs.
Cycle & Status… Service Menu…
Price Menu… Initialization Menu…
Wash Cycle Menu… Configuration Menu…
Main Menu
