18 PROGRAMMING MANUAL 516532 B PUBLICATION DATE 1 JUN 2007.DOC
5.2. CONFIGURATION MENU
This electronic managing system has been specially constructed for a wide range of washing machines.
For that reason it must be individually set up with important parameters for various machine sizes. Basic
machine adjustments were made at the factory.
WARNING !
ONLY A QUALIFIED TECHNICIAN SHOULD CHANGE THE CONFIGURATION SET UP. AN INCORRECT
CONFIGURATION CAN CAUSE INJURIES AND SERIOUS MACHINE DAMAGE.
T HOW TO GET INTO THE CONFIGURATION MENU
The Configuration Menu requires a password to enter. To get into the Configuration Menu press enter, then
following sequence of buttons bright colors, colors and then whites followed by the enter button.
ATTENTION
!!!
BE SURE THAT YOU WANT TO ERASE THE OLD SETTINGS, AS THEY CAN’T BE RECAPTURED.
CHANGING THE MACHINE SIZE SHOULD ONLY OCCUR WHEN A NEW MCG WASH
COMPUTER IS INSTALLED.
ATTENTION
!!!
BE SURE THAT YOU HAVE SELECTED THE CORRECT MACHINE SIZE, OTHERWISE THE MACHINE
WILL NOT FUNCTION PROPERLY.
ATTENTION
!!!
BY CHANGING THE MACHINE SIZE THE WASH PROGRAMS, KEPT IN THE EEPROM MEMORY,
ARE NOT CHANGED.
AFTER CHANGING THE WASH MACHINE SIZE IT’S RECOMMENDED TO ERASE THE PROGRAM
MEMORY AND LOAD THE STANDARD WASH PROGRAMS AGAIN.
THE WASH PROGRAM SETTINGS DIFFER FOR EACH MACHINE SIZE
ATTENTION
!!!
SELECTING FACTORY RESET IS RECOMMENDED IF A NEW MACHINE SIZE HAS BEEN
SELECTED. THIS WILL ENSURE THAT ALL THE DEFAULT SETTINGS OF THE NEW MACHINE SIZE
ARE LOADED.
!
!
!
!
!
Cycle & Status… Service Menu…
Price Menu… Initialization Menu…
Wash Cycle Menu… Configuration Menu…
Main Menu
To Next Page
