FOR SERVICE TECHNICIAN’S USE ONLY
17
AUTOMATIC TEST MODE CHART/COMPONENT ACTIVATION
Step# Action Component HMI response
1
User enters Automatic test mode through
Service Diagnostics by pressing
releasing Key 2 used in entry sequence.
Lid must be closed. All LEDs are OFF and machine is waiting for the
START button to be pressed.
2
Press and release the START button to
begin the test. Water valves test starts
automatically.
Water Valves Test Sequence:
dz Cold Water Valve Opens for 10 seconds
or until 70 mm water is filled and then
closes.
dz Hot Water Valve Opens for 10 seconds
and closes.
Sense LED from Status Indicators is ON during
this sequence.
3
Drain pump test starts automatically.
1. Press Key 1 to repeat the Water
Valve test sequence.
2. Press Key 2 to skip the Drain Pump
test sequence.
Drain Pump Test Sequence:
dz Drain Pump Turns ON for 45 seconds or
till reaching 3 mm water column in the
tub.
Soak Phase LED from status indicator is ON
during this sequence.
4
Wash Sequence starts automatically.
1. Press Key 1 to repeat the Drain test
sequence.
2. Press Key 2 to skip the wash test
sequence.
Wash Test Sequence:
dz Lid Lock closes.
dz Shifter changes its position to wash.
dz Wash action performed for 5 seconds in
both CW/CCW.
dz Lid Unlocks.
Wash LED from Status Indicators is ON during
this sequence.
5
Spin Test sequence starts automatically.
1. Press Key 1 to repeat wash test
sequence.
2. Press Key 2 to skip spin test
sequence.
Spin Test Sequence:
dz Lid Lock closes.
dz Shifter changes its position to spin.
dz Slow spin at 140 rpm for 5 seconds.
dz Medium spin at 300 rpm for 5 seconds.
dz Final spin at 500 rpm for 30 seconds
or skip after 25 seconds if 500 rpm not
reached.
dz Lid Unlocks after basket speed comes to
less than 60 rpm.
Done LED from Status Indicators is ON during this
sequence.
6
End of Service Cycle starts automatically.
1. Press Key 1 to repeat spin test
sequence.
2. Press Key 2 to skip water valves test
sequence.
3. No key press will take to Service
mode.
End of cycle sequence:
dz Shifter turn to wash.
All LEDs from Status Indicators is ON during
this sequence.
