FOR SERVICE TECHNICIAN’S USE ONLY
41
Removing the Lid and Hinge
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
Top Load Washer Glass Lid
Removal
1. Remove the four (4) TORX T20 screws holding the lid to the hinges.
2. Lift the lid up and off of the hinges.
Top Load Washer Hinge Removal
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
1. Complete the steps 1-7 from section Removing the Console.
2. Complete the steps 1-2 from section Remove the Lid and Hinge.
3. Remove the 1/4" (6 mm) hex head screw holding the hinge in place.
4. Slide the hinge back and lift it to remove.
