Maytag Pet Pro - Section 4: Component Access; Console and User Interface Removal; Water Inlet Valve and Main Control Removal; Pet Hair Filter and Agitator Removal

FOR SERVICE TECHNICIAN’S USE ONLY
33
Section 4:
Component Access
This section provides service parts access, removal, and replacement
instructions for the “Maytag
®
Pet Pro System Top Load Washer.”
■ Removing the Console
■ Removing the User Interface (UI)
■ Removing the Water Inlet Valve
■ Removing the Main Control
■ Removing the Pet Hair Filter
■ Removing the Agitator
■ Removing the Tub Ring and Basket
• Lifting the Top Panel
• Removing the Tub Ring
• Removing the Basket
■ Removing the Lid Lock
■ Removing the Lid and Hinge
• Top Load Washer Glass Lid Removal
• Top Load Washer Hinge Removal
■ Removing the Shifter
■ Removing the Drain Pump
■ Removing the Drive Belt and Motor
■ Removing the Splutch
■ Removing the Gearcase
