Output On/Off Details
UI Component Test N/AUpon activation, all LEDs are turned on. Pressing each button turns off
its LED. Pressing the ATM buttons and rotating the cycle selector knob
changes their on-screen representations from black to green. Press
and hold the lower-left ATM button to return to previous screen.
Motor YES Status (On/Off) NOTE: Door must be closed.
If the motor does not turn on, go to TEST #3, page 12.
Heater1 (Electric)/ Heat On (Gas) YES Status (On/Off) NOTE: Door must be closed.
Attributes: Exhaust & Inlet Thermistor Reading.
When you turn on heat, the motor is turned on as well. If temp is
too high, system will automatically turn off heat.
• If the motor does not turn on, go to TEST #3, page 12.
• If no heat is detected, go to TEST #4, page 13.
Inlet ThermistorN/A Status (F°, C°, and Resistance)
If inlet thermistor reading is out of range, go to TEST #4a, page 15.
Exhaust ThermistorN/A Status (F°, C°, and Resistance)
If exhaust thermistor reading is out of range, go to TEST #4a, page 15.
Moisture Sensor N/AStatus (Open/Closed)
• Place finger over both sensor strips. If sensor status does not change,
go to TEST #5, page 18.
Door Status N/AStatus (Open/Closed)
• If opening the door does not change status, go to TEST #7, page 20.
CCU Line Voltage 1N/A Status (L1 Voltage Measurement) NOTE: Door must be closed.
When measuring L1, the motor and heater are activated.
• If L1 is absent, go to TEST #1, page 9.
CCU Line Voltage 2 (Electric Only)N/A Status (L2 Voltage Measurement) NOTE: Door must be closed.
When measuring L2, the motor and heater are activated.
• If L2 is absent, go to TEST #1, page 9.
Air Flow N/AStatus (Normal/Restricted) NOTE: Door must be closed.
• If air flow does not turn on, go to TEST #4, page 13.
Drum Light YES Status (On/Off)
• If drum light does not turn on, go to TEST #8, page 20.
Buzzer YES Status (On/Off)
• If buzzer does not sound, go to TEST #6, page 19.
Myst Valve YES Status (On/Off) After being turned on, the myst valve automatically
deactivates after 30 seconds if not turned off.
• If myst valve does not turn on, go to TEST #9, page 21.
COMPONENT ACTIVATION CHART
CCU Heater Voltage (Electric Only)N/A Status (L1 + L2 Voltage Measurement) NOTE: Door must be closed.
When measuring Heater Voltage, the motor and heater are activated.
• If Heater Voltage (L1 + L2) is absent, go to TEST #1, page 9.
Code Description Explanation and Recommended Procedure
PF Power FailurePF indicates that a power failure occurred while the dryer was running. Press START to resume
the cycle, or press POWER to clear the display.
AF Restricted Air Flow Indicates low air flow that may affect dryer performance.
Confirm that airflow system is not blocked. Check lint screen, exhaust duct, exhaust fan.
• Refer to Fault/Error Code “F4E3”, page 7, for recommended procedure.
L2 Low Line Voltage L2 indicates low L2 voltage (less than 30 V) is detected at the CCU.
• Refer to Fault/Error Code “F4E4”, page 7, for recommended procedure.
