GENERAL INFORMATION
00–00–10
Inspection
• When a tester is used to inspect for continuity or
measuring voltage, insert the tester probe from
the wiring harness side.
• Inspect the terminals of waterproof connectors
from the connector side since they cannot be
accessed from the wiring harness side.
Caution
•
••
• To prevent damage to the terminal, wrap
a thin wire around the tester probe before
inserting into terminal.
End Of Sie
GOOD
NO GOOD
CHU0000W011
GOOD NO GOOD
CHU0000W012
