GENERAL INFORMATION
00–00–2
Engine Workshop Manual 13B-MSP (Multi Side Port) (1773–1U–03C)
Service Procedure
Inspection, adjustment
• Inspection and adjustment procedures are
divided into steps. Important points regarding the
location and contents of the procedures are
explained in detail and shown in the illustrations.
49 H002 671
49 H032 322
49 1232 670A
SHOWS PROCEDURE ORDER
FOR SERVICE
Fluid Pressure Inspection
1. Assemble the SSTs as shown in the figure.
Tightening torque
SHOWS TIGHTENING
TORQUE
SPECIFICATIONS
Caution
Connect the gauge set from under
the vehicle to prevent contact with
the drive belt and the cooling fan.
39—49 N·m {4.0—5.0 kgf·m, 29—36 ft·lbf}
WGIWXX0009E
To Next Page
