Bulb type
Running lights/Position lights (Type B)
1. Make sure the ignition is switched
o, and the headlight switch is o.
2. If you are changing the left bulb,
start the engine, turn the steering
wheel all the way to the right, and
turn o engine. If you are changing
the right bulb, turn the steering
wheel to the left.
3. Pull the centre of each plastic
retainer and remove the retainers.
1. Removal
2. Installation
4. Pull the centre of each plastic
retainer and remove the retainers.
1. Removal
2. Installation
5. Turn the screw anticlockwise and
remove it, and then partially peel
back the mudguard.
6. Turn the socket and bulb assembly
anticlockwise and remove it.
7. Disconnect the bulb from the
socket.
8. Install the new bulb in the reverse
order of the removal procedure.
Maintenance and Care
Owner Maintenance
6-49
