4 - 2
Attaching Machine to Pipe
Refer to the "Machine Setup" section for attaching the machine.
Place the machine on the pipe in the desired vertical or
horizontal position. Tighten the clamp knobs until the pipe
conforms to the clamping inserts.
NOTICE: Do not overtighten when clamping on the pipe.
Overtightening can flatten the pipe and make it
difficult to obtain a melt pattern
Preparing the Pipe
Clean the pipe in the area the fitting will come into contact.
Rough up the pipe with 50 or 60 grit utility cloth, scraping tool,
or other procedure specified by the pipe manufacturer, fitting
manufacturer, or applicable standard.
Preparing the Fitting
Clean the base of the fitting.
Rough up the pipe with 50 or 60 grit utility cloth, scraping tool,
or other procedure specified by the pipe manufacturer, fitting
manufacturer, or applicable standard.
Operation
PH00783-5-9-96
PH00787-4-3-96
PH00788-4-3-96
TX00951-5-13-96
TX00923-7-30-10
TX00924-7-30-10
