4 - 5
Operation
Disengage Pivot Release Master
Unscrew pivot release clamp knob to disengage pivot release
master insert assembly from fitting.
Unclamp and Remove Machine
Loosen clamp knobs on base. Open jaws or disengage chains
and remove the machine.
Fusing Fitting to Pipe
After removing the heater, immediately bring the fitting down to
the pipe, apply fusion pressure. Maintain pressure until cooling
time is complete.
NOTICE: Failure to follow pipe manufacturer's heating time,
pressure and cooling time can result in a bad joint.
