5 - 2
Maintenance
Fasteners Must Be Tight
Check all nuts, bolts, and snap rings to make certain they are
secure and in place.
Clean and Lubricate Bearings
All clamp knobs are equipped with thrust bearings to reduce
friction and improve efficiency of the clamping screw. Wash the
clamp knob bearing assembly with a solvent and then lubricate
with a 30W or lighter oil.
Clean Eyebolt Threads
Keep the clamp knob eyebolt threads brushed clean.
Remove Dirt
Remove dirt from jaw and insert serrations, drive screw, and
clamp knob eyebolts.
PH00724-2-21-96
PH00833-5-6-96PH00833-5-6-96
PH00831-5-3-96
TX00865-1-30-96
TX00866-9-22-10
TX00435-9-13-94
TX00437-9-13-94
