McElroy Sidewinder - Specifications; Sidewinder Specifications

Sidewinder
Specification: Designed for 4" and smaller branch saddles,
tapping tees and smaller fittings
Dimensions:
Chain Clamp: Width: 12.5" (318mm)
Length: 12.5" (318mm)
Height: 26.5" (673mm)
Weight: 28 lbs (13Kg)
Compact Chain Clamp: Width: 12.5" (318mm)
Depth: 12.5" (318mm)
Height: 21.4" (546mm)
Weight: 27 lbs (12Kg)
Jaw Clamp: Width: 10.5" (267mm)
Length: 7.75" (203mm)
Height: 28" (711mm)
Weight: 26 lbs (11.7Kg)
Compact Jaw Clamp: Width: 10.5" (267mm)
Depth: 7.75" (203mm)
Height: 23" (584mm)
Weight: 25 lbs (11Kg)
Heaters: 2", 800 W, 100-120 V, 50/60 Hz
2", 800 W, 200-240 V, 50/60 Hz
4", 1,200 W, 100-120 V, 50/60 Hz
4", 1,200 W, 200-240 V, 50/60 Hz
Specifications
TX00995-6-6-13
7 - 1
