Reel Disk from McFarlane Mfg. 96 800-627-8569
Layout Diagram for RD-4120
8 BLADE 9 BLADE 9 BLADE 8 BLADE
51 58 66 51
51 73 62 51
52
74 63
52
FA-500-3
FA-700-3 FA-600-3
FA-500-3
