33
Manual No. 4111-0019
May 2015
July 2016
PARTS
Platform Components
1
Must provide dock leveler serial number, platform size, capacity, any options and lip size when calling
or faxing orders.
2 1 DPLA-0338 LIP BANGER ASSY.
3 2 DPLA-0341 BAR
4 1 DPLA-0353 BELOW DOCK PULL CHAIN
9 1 DPLA-0343 BELOW DOCK CONTROL ASSY.
10 2 DOTH-2382 PIN, COTTER
11 1 DOTH-2074 BOLT, HEX 5/8-11 X 2.00
12 1 DOTH-2160 NUT, HEX 5/8-11
17 1 DPLA-0360 BDC PUSH ROD ASSY
18 1 DOTH-2060 BOLT SHOULDER
19 1 DOTH-2131 LOCK NUT
20 1 DOTH-6406 LIP ASSIST ROD
23 1 DOTH-2550 SPRING ,LIP ASSIST STD (CONSULT FACTORY)
24 1 DOTH-2546 SPRING ,LIP ASSIST HEAVY (CONSULT FACTORY)
25 1 DOTP-2006 LIP PROP BAR
26 1 DOTH-2062 SHOULDER BOLT
27 1 OTH-2131 LOCK NUT
28 2 OTH-2214 WASHER
29 1 DOTH-2547 SPRING COMPRESSION
30 1 DOTH-2582 SHOCK GAS
31 1 DOTH-2351 BOLT CLEVIS
32 2 DOTH-2374 PIN COTTER
33 4 DOTH-2210 WASHER, FLAT
34 2 DOTH-2163 LOCK NUT
35
LIP SHAFTS
2 DPLA-2101 6.0 FOOT
2 DPLA-2102 6.5 FOOT
2 DPLA-2103 7.0 FOOT
36 2 DOTH-2355 PIN , CLEVIS
37 2 DOTH-2373 PIN, COTTER
39 2 2101-0079 WASHER, FLAT
38
LIPS
6.0 FOOT 25K 30K 35K 40/45K 55K
1 16 0595-5000 0595-5009 0595-5018 0595-5027 0595-5036
1 18 0595-5001 0595-5010 0595-5019 0595-5028 0595-5037
1 20 0595-5002 0595-5011 0595-5020 0595-5029 0595-5038
6.5 FOOT
1 16 0595-5003 0595-5012 0595-5021 0595-5030 0595-5039
1 18 0595-5004 0595-5013 0595-5022 0595-5031 0595-5040
1 20 0595-5005 0595-5014 0595-5023 0595-5032 0595-5041
7.0 FOOT
1 16 0595-5006 0595-5015 0595-5024 0595-5033 0595-5042
1 18 0595-5007 0595-5016 0595-5025 0595-5034 0595-5043
1 20 0595-5008 0595-5017 0595-5026 0595-5035 0595-5044
Spring Information on page 34.
