PARTS
Platform Components
55 SEE CHART DOTH-2570 SPRING MAIN 6620
56 SEE CHART DOTH-2574 SPRING MAIN 6635
57 SEE CHART DOTH-2576 SPRING MAIN 6820
58 SEE CHART DOTH-2578 SPRING MAIN 6835
6 FOOT LONG
6.0 FOOT 25K 30K 35K 40K 45K 55K
16 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
18 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
20 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
6.5 FOOT
16 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
18 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
20 (4)55 (4)55 (4)55 (4)55 (4)55 (1)55, (2)56
7.0 FOOT
16 (4)55 (4)55 (4)55 (4)55 (2)55, (2)56 (2)55, (2)56
18 (4)55 (4)55 (4)55 (4)55 (2)55, (2)56 (2)55, (2)56
20 (4)55 (4)55 (4)55 (4)55 (2)55, (2)56 (2)55, (2)56
8 FOOT LONG
6.0 FOOT 25K 30K 35K 40K 45K 55K
16 (4) 55 (4) 57 (4) 57 (4) 57 (4) 57 (4) 57
18 (4) 55 (4) 57 (4) 57 (4) 57 (4) 57 (4) 57
20 (4) 55 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (2)57, (2)58
6.5 FOOT
16 (4) 57 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (2)57, (2)58
18 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (2)57, (2)58 (2)57, (2)58
20 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (2)57, (2)58 (2)57, (2)58
7.0 FOOT
16 (4) 57 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (4)58
18 (4) 57 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (4)58
20 (4) 57 (4) 57 (4) 57 (2)57, (2)58 (2)57, (2)58 (4)58
10 FOOT LONG
6.0 FOOT 25K 30K 35K 40K 45K 55K
16 (8) 57 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
18 (8) 57 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
20 (8) 57 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
6.5 FOOT
16 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
18 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
20 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58
7.0 FOOT
16 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58 (8) 58
18 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58 (8) 58
20 (4) 57, (4) 58 (4) 57, (4) 58 (4) 57, (4) 58 (8) 58 (8) 58 (8) 58
