McHale 995 TSR User Manual

McHale 995 L+T Square Bale Wrapper
10
T Series
2.6 General dimensions & specifications
Check with national road traffic regulations in the individual country!
2.7 Tractor attachment
2.8 Machine specifications
Transport length 3.5 m (11’ 6”)
Transport width 1.91 m (6’ 3”)
Transport height 2.00 m (6’ 7”)
Height to top of rollers 0.97 m (3’ 2”)
Transport weight (unladen) 1,150 kg (2,535 lbs)
Tyre dimensions 20.5 x 8.00 -10
Tyre pressure 3.4 bar/50 psi
Maximum road speed 40 km/h (25 mph)
Attachment Pin hitch
Towing tractor requirements 35 kw
Electrics 12 Volt DC, 7 amp approx.
Hydraulic systems Load sensing, open centre, closed centre
Minimum hydraulic pressure 160 bar (2,350 psi)
Minimum hydraulic flow rate 18 l/min (4 gal/min)
Maximum rotary table speed 30 rpm
Film stretch 55% (64% optional)
Film layers 2+2 system
Film width 750 mm
Maximum bale size (Square)
W: 800-900 mm, H: 600-1,000 mm,
L: 1,800 mm
Maximum bale size (Round) W: 1,500 mm, D: 1,500 mm
Maximum bale weight 1,000 kg (2,205 lbs)

McHale 995 TSR Specifications

General

Brand	McHale
Model	995 TSR
Category	Stretch Wrapping Systems
Language	English
