McHale 995 TSR User Manual

McHale 995 L+T Square Bale Wrapper
4
Table of Contents
1 Introduction 6
2 Product Information 7
2.1 Designated use of the machine 7
2.2 Front view 8
2.3 General Dimensions & specifications 9
2.4 Tractor attachment 9
2.5 Machine specifications 9
2.6 General dimensions & specifications 10
2.7 Tractor attachment 10
2.8 Machine specifications 10
3 General Safety 11
3.1 Be aware of all safety information 11
3.2 Follow all safety instructions 11
3.3 Store all items carefully 12
3.4 Protective clothing 12
3.5 In case of emergencies 12
3.6 Stay clear of moving parts 12
3.7 In the event of a fire 12
3.8 General safety warnings 13
4 Specific Safety Warnings 16
4.1 Electronic safety warnings 16
4.2 Hydraulic safety warnings 16
4.3 Noise level 17
4.4 Fire precautions 17
4.5 Safety instruction decal locations 18
4.6 Safety warnings & instructions explained 19
4.7 Machine lifting guidelines 22
5 Tractor Requirements & Preparation 23
5.1 Tractor/power pack requirements 23
5.2 Hydraulic spool valve setup 24
5.3 Attaching the wrapper (L Series) 25
5.4 Attaching the wrapper (T Series) 25
5.5 Connecting the control box 26
6 Bale & Plastic Film Requirements 27
6.1 Bale Requirements 27
6.2 Plastic Film Requirements 28
6.3 Care of the film roll 29
7 Manual Controls (995 L & LS) 30

McHale 995 TSR Specifications

General

Brand	McHale
Model	995 TSR
Category	Stretch Wrapping Systems
Language	English
