McHale 995 TSR User Manual

McHale 995 L+T Square Bale Wrapper
26
5.5 Connecting the control box
The control box is to be connected to a 12 V / 20 Amp power supply either using the
supplied euro socket or the battery power cable. A good power supply is critical for
proper machine operation as the electronic control box is the main interface between
the operator and the machine.
Figure 5.c - Bale Wrap Computer Figure 5.d - Electronic Control Box
Figure 5.e - Hoses and cable
CAUTION: Do not connect control box to a 24 V power supply
Do not attempt to connect control box to a 24 V power supply, as
machine component damage will result.
