McHale 995 TSR User Manual

McHale 995 L+T Square Bale Wrapper
62
Figure 11.j - Horizontal adjustment
11.7.2 Vertical adjustment
1. Support the cut & hold
2. Remove the 4 x M16 bolts and nyloc nuts holding on the cut & hold
3. Move the cut & hold to a new position and secure the 4 x M16 bolts and nyloc
nuts
Figure 11.k - Vertical adjustment
11.8 Cut & hold accumulator pressure
The cut & hold is held open by a hydraulic accumulator which is primed before leaving
the factory. If, for whatever reason, the pressure drops or increases it is possible to
prime the circuit again, as follows.
WARNING: Care must be taken when carrying out this procedure
It is very import that care is taken in carrying out the following procedure
to protect both the operator and any personnel that may be nearby! If you
are unsure of how to carry out this procedure entrust the job to your
McHale dealer.
