McHale 995 TSR User Manual

McHale 995 L+T Square Bale Wrapper
9
L Series
2.3 General Dimensions & specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
2.4 Tractor attachment
2.5 Machine specifications
Transport length 3.1 m (10’2”)
Transport width 1.73 m (5’ 8”)
Transport height 1.97 m (6’ 6”)
Height to top of rollers 0.97 m (3’ 2”)
Transport weight (unladen) 1,050 kg (2,315 lbs)
Attachment Category 2, three point linkage
Electrics 12 Volt DC, 7 amp approx.
Hydraulic systems Load sensing, open centre, closed centre
Minimum hydraulic pressure 160 bar (2,350 psi)
Minimum hydraulic flow rate 18 l/min (4 gal/min)
Maximum rotary table speed 30 rpm
Film stretch 55% (64% optional)
Film layers 2+2 system
Film width 750 mm
Maximum bale size (Square)
W: 800-900 mm, H: 600-1,000 mm,
L: 1,800 mm
Maximum bale size (Round) W: 1,500 mm, D: 1,500 mm
Maximum bale weight 1,000 kg (2,205 lbs)

McHale 995 TSR Specifications

General

Brand	McHale
Model	995 TSR
Category	Stretch Wrapping Systems
Language	English
