McHale 995 L+T Square Bale Wrapper
54
The electronic control box (if fitted) should be set to program “R94”. If side loading is
desired use program “SR94”. The table must be in the correct starting position. Refer
to “Electronic Control Box Functions” on page 41 for more details.
1. Park the machine on level ground with access for the loader, as required.
Ensure the machine cannot move.
2. Load the bale onto the wrapper table using a McHale square bale handler.
3. The wrapper should now go through a sequence either worked manually or
automatically, on electronic machines.
(a) Press “Auto start” on the remote control unit (995 LSR) or use manual
hydraulic controls (995 L / 995 LS)
(b) The table starts rotating and plastic film is applied to the bale
(c) After a few revolutions the cut & hold releases the plastic film
(d) The table slows down two revolutions before the required number of
revolutions is reached (995 LSR)
(e) The table stops rotating when the required number of rotations is
reached. It is now lined up for tipping off.
(f) To tip the bale off, “auto start” must be pressed again (995 LSR)
(g) The table tips half way
(h) The cut and hold closes, holding and cutting the plastic film
(i) The table tips up fully and the bale rolls to the ground
4. The wrapper is now ready to receive another bale.
WARNING: Keep out of the “Danger Zone”
Keep all persons outside of the “Danger Zone” during all machine
operations! See “Danger Zone” on page 13.
WARNING: Ensure the area is clear before operating the wrapper
Always ensure there is no person or wrapped bales in the way of the
wrapper before operating it again.
WARNING: Turn off power before changing plastic film rolls
Always turn off the power source and the electronic control box, before
changing the plastic film roll.
