McHale F5400 Baler
32
5
Tractor requirements & preparation
5.1 Tractor requirements
The minimum recommended size of tractor for operating the machine comfortably
depends mainly on the crop condition and the required cut length of the forage. On flat
ground McHale recommends a tractor size of approximately 60 kW. On hilly ground or
difficult conditions, an additional 10 to 15 kW is advisable.
The following items on the tractor are required for attachment of the machine behind
the tractor:
1.
Low/high drawbar hitch* that is suitable for an imposed load of minimum 3,800 kg
2. Two double-acting spools (½” female quick-release) one with float position for
the pick-up reel
3. Hydraulic-brake coupling (or two air-brake couplings), if brakes are fitted
4. 12 V / 7-pin socket for lighting
5. 12 V, 20 A euro socket or battery power cable
6. 1 ⅜”, 6-spline PTO shaft (set to a speed of 540 rpm)
*
Depending on country of use
5.2 Control box installation
A good power supply is critical for proper machine operation as the electronic control
box is the main interface between the operator and the machine. The electric power
supply is obtained from the euro socket of the tractor.
NOTE: Use good quality oil
Ensure that the tractor has clean, good quality, hydraulic/universal oil to
avoid problems later on. Also, the hydraulic filters on the tractor should
be changed regularly, according to the manufacturer’s service
instructions. Avoid dirt getting into the hydraulic couplings.
CAUTION: Electrical power supply
Do not use any other electric power supply for the electronic control
system, otherwise damage may occur.
