McHale F5400 Baler
4
Table of contents
1 Introduction 8
2 Product information 9
2.1 Designated use of the machine 9
2.2 Front view 10
2.3 Rear view 11
2.4 General dimensions & specifications 12
2.5 Tractor attachment 12
2.6 Machine specifications 13
2.7 Tyre specifications 13
3 General safety 14
3.1 Be aware of all safety information 14
3.2 Follow all safety instructions 14
3.3 Store all items carefully 15
3.4 Protective clothing 15
3.5 In case of emergencies 15
3.6 Stay clear of rotating elements 15
3.7 Operating the machine 15
3.8 In the event of a fire 16
3.9 General safety warnings 16
4 Specific safety warnings 20
4.1 Electronic safety warnings 20
4.2 Hydraulic safety warnings 20
4.3 Noise level 21
4.4 Fire precautions 21
4.5 Special safety devices/instructions 21
4.6 Safety instruction decal locations 22
4.7 Safety warnings & instructions explained 23
4.8 Description of the serial number plate 30
4.9 Machine lifting guidelines 31
5 Tractor requirements & preparation 32
5.1 Tractor requirements 32
5.2 Control box installation 32
5.3 Attaching to drawbar 33
5.4 Attaching break-away brake (if fitted) 33
5.5 Attaching the machine to a 540 rpm PTO 34
5.6 Lighting system 34
5.7 Attaching hydraulic hosing to the tractor 34
5.8 Connecting the control box 35
