Electronic control system
The control box is the main interface between the operator and the baler and can be
operated in manual or auto mode. All the functions are shown on the diagram opposite
with the relevant instructions for setting and re-setting in the following pages.
Please see the pull-out guide for this electronic control system at the end of this
chapter. This can be removed and laminated to keep in your tractor and familiarise
yourself with the functions of the controller.
