McIntosh MC601 User Manual

18
Specications
Specications
Power Output
Minimum sine wave continuous average power output
is:
600 watts into 2 ohm load
600 watts into 4 ohm load
600 watts into 8 ohm load
Output Load Impedance
2, 4 or 8 ohms
Rated Power Band
20Hz to 20,000Hz
Total Harmonic Distortion
0.005% maximum harmonic distortion at any power
level from 250 milliwatts to rated power, 20Hz to
20,000Hz
Dynamic Headroom
1.8dB
Frequency Response
+0, -0.25dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 100,000Hz
Input Sensitivity (for rated output)
4.8 Volts Balanced
2.4 Volts Unbalanced
Signal To Noise Ratio (A-Weighted)
96dB Balanced (124dB below rated output)
94dB Unbalanced (122dB below rated output)
Intermodulation Distortion
0.005% maximum, if the instantaneous peak power
output does not exceed twice the rated power output
for any combination of frequencies from 20Hz to
20,000Hz.
Wide Band Damping Factor
Greater than 40
Input Impedance
22,000 ohms Balanced
22,000 ohms Unbalanced
Voltage Gain
29dB, 8 Ohms
26dB, 4 Ohms
23dB, 2 Ohms
Power Guard
Less than 2% Total Harmonic Distortion with up to a
14dB overdrive signal
Power Control Input
5-15VDC, less than 1mA
Power Control Output 1 and 2
12VDC, 50mA maximum total
Output is delayed 0.2 seconds from turn On
Power Requirements
Field AC Voltage conversion of the MC601 is not
possible. The MC601 is factory configured for one of
the following AC Voltages:
100V ~ 50/60Hz at 8 Amps
110V ~ 50/60Hz at 6.6 Amps
120V ~ 50/60Hz at 6.6 Amps
220V ~ 50/60Hz at 3.6 Amps
230V ~ 50/60Hz at 3.3 Amps
240V ~ 50/60Hz at 3.3 Amps
Standby: less than 0.5 watt
Note: Refer to the rear panel of the MC601 for the cor-
rect voltage.
Overall Dimensions
Width is 17-1/2 inches (44.45cm)
Height is 9-7/16 inches (23.97cm) including feet
Depth is 22 inches (55.88cm) including the Front
Panel, Handles and Cables
Weight
93 pounds (42.18 kg) net, 126 pounds (57.15 kg) in
shipping carton
Shipping Carton Dimensions
Width is 29-1/2 inches (74.93cm)
Height is 17 inches (43.18cm)
Depth is 29 inches (73.66cm)

McIntosh MC601 Specifications

General

Damping factor	40
Amplifier class	-
Frequency range	10 - 100000 Hz
Output impedance	8 Ω
Audio output channels	1.0 channels
Peak power per channel	600 W
Signal-to-Noise Ratio (SNR)	124 dB
Total Harmonic Distortion (THD)	0.005 %
XLR in	Yes
XLR out	1
Speakers connectivity type	Binding post
Purpose	Performance/stage
Product color	Aluminium, Black
Volume control	Rotary
Connectivity technology	Wired

Weight and Dimensions

Depth	558.8 mm
Width	444.5 mm
Height	239.7 mm
Weight	42180 g
