f. Strainer
The strainer is an important element in the piping system to remove particles (e.g. sand)
and dirt from the water. If not, these impurities will damage the pumping mechanism and
clogged-up valves and fittings.
IMPORTANT!!!
The mini chiller unit do not have a strainer built-in. Always install a strainer on
the water inlet pipe into the chiller to protect the internal water pump.
straine
CHILLER
water outlet
water inlet
Do not install strainer on the water outlet pipe as the water velocity is higher.
Install the strainer with the filter element in a downward position. This is to facilitate easy
flushing during periodic cleaning.
allow sufficient s
