water inlet
filter mesh 16 – 20
recommended
There is also a practice to install a strainer on the inlet pipe to a fan coil unit. This is
done to protect the control valve, located at the outlet pipe, from clogging.
straine
FAN COIL UNIT
2-way valve
to measure th water te peratur
stallation can be done with a socket welded onto the pipe or a tee joint connection.
g. Thermometer
Glass thermometers are installed on the inlet and outlet pipes of either the chiller unit
or fan coil units. This is e m e differential to determine the
capacity performance.
Usually, these thermometers are installed together with the pressure gauges.
In
r
threaded
