McQuay GZ 035AM

IOMM ACZ/AGZ-1 85
Table 41, MENU 15 SoftLoad Spts
Screen Display Factory Setpoint Range
1 Time Left= xxmin
2 SoftLoad= xx min 20 0 - 254
3 SoftLdMaxStg= x 4 1 - 4
4 LoadDelay= xxsec 15 0 - 254
Table 42, MENU 16 CompressorSpt
Screen Display Factory Setpoint Range
1 Sequence=Auto Auto
1234
1432
2143
2341
3214
3412
4123
4321
2 StageUp= xxx sec
3 StageDn= xxx sec
4 MinST-ST=xx min 15 5 - 40
MinSP-ST xx min 3 - 30
Comp #1 Disable / Enable
Comp #2 Disable / Enable
Comp #3 Disable / Enable
5
Comp #4
5
Disable / Enable
Table 43, MENU 17 Head Pres Spt
Values for R-22 refrigerant, ( ) indicates Centigrade values
Screen Display Factory Setpoint Range
1 MinLift 50%=xxx 90 (621) 70 - 100 (483 - 690)
2 MinLift100%=xxx 120 (828) 100 - 140 (690 - 966)
3 DeadBand 50%= x.x 50 0 - 255
4 DeadBand100% = x.x 90 0 - 255
5 Cond Pres 1 = xxx 200 180 - 220
6 Cond Pres 2 = xxx 300 280 - 320
7 StageUpErr= xxx 400 (2760) 300 - 990 (2070 - 6830)
8 StageDnErr = xxx 100 (690) 50 - 400 (340 - 2760)
Table 44, MENU 17 Head Pres Spt
Values for 134a refrigerant, ( ) indicates Centigrade values
Screen Display Factory Setpoint Range
1 MinLift 50%=xxx 50 (345) 50 - 80 (345 - 552)
2 MinLift100%=xxx 70 (483) 80 - 122 (552 - 841)
3 DeadBand 50%= x.x 23 0 - 255
4 DeadBand 100% = x.x 50 0 - 255
5 CND PRS 1 = xxx 128 180 - 220
6 CND PRS 2 = xxx 201 280 - 320
7 StageUpErr= xxx 275 (1897) 300 - 990 (2070 - 6830)
8 StageDnErr = xxx 57 (393) 50 - 400 (340 - 2760)
Table 45, MENU 18 Demand Limits
Screen Display Factory Setpoint Range
1 Demand Lim= xstg 3 Not Changeable at this screen
2 DemandSg= xx.x ma Actual Value
Indicates the Magnitude of the
Demand Limit Signal
Table 46, MENU 19 Time / Date
Screen Display Factory Setpoint Range
1 Time= xx:xx:xx Actual Time
2 Mon xx/xx/xx Actual Day and Date
