Installation and maintenance are to be performed only by qualified personnel who are familiar
with local codes and regulations, and experienced with this type of equipment.
Caution: Sharp edges and coil surfaces are a potential injury hazard. Avoid contact with them.
Contents
Page
Nomenclature System .............................................................................................. 1
Features..................................................................................................................... 2
Performance Tables.................................................................................................. 4
Outlines and Dimensions........................................................................................ 15
Section Weights....................................................................................................... 23
Installation................................................................................................................ 25
Operation.................................................................................................................. 27
Maintenance............................................................................................................. 28
Troubleshooting....................................................................................................... 30
“McQuay” is a registered trademark of McQuay International. All rights reserved throughout the world.
© 2003 McQuay International
“Bulletin illustration cover the general appearance of McQuay International products at the time of publication and we
reserve the right to make change in design and construction any time without notice”
Moving machinery and electrical power hazard. May cause severe personal injury or
death. Disconnect and lock off power before servicing equipment.
