McQuay MDM Series User Manual

24
Fan Weights
MODEL 0306 0308 0408 0410 0509 0510 0511 0610
FAN SIZE (mm)
160 160*2 250 250G2 315 315 315 355
WEIGHT (kg)
8.4 17 18 36 29 29 29 38
MODEL 0611 0612 0711 0712 0713 0812 0813 0913
FAN SIZE (mm)
400 400 450 450 450 500 500 560
WEIGHT (kg)
48 48 60 60 60 88 88 110
MODEL 0914 1014 1015 1115 1116 1216 1217 1317
FAN SIZE (mm)
560 630 630 630 710 710 710 800
WEIGHT (kg)
110 122 122 122 228 228 228 286
MODEL 1417 1518 1618 1719 1820 1822 1825 1826
FAN SIZE (mm)
800 900 900 900 1000 1000 1120 1120
WEIGHT (kg)
286 348 348 348 406 406 900 900
Motor Weights
MOTOR OUTPUT
1.1 kW 1.5 kW 2.2 kW 3 kW 4 kW 7.5 kW 11 kW
WEIGHT (kg)
20 22 30 30 42 65 118
MOTOR OUTPUT
15 kW 18.5 kW 22 kW 30 kW 37 kW 45 kW
WEIGHT (kg)
139 189 203 290 320 348
