34 Product Manual PM WSC/WDC
WSC 063, 160 to 300 tons
VESSEL CODE OVERALL LENGTH CONNECTIONS
1&3
PASS
2
PASS
HEAD CONN.
BOTH ENDS
OVERALL
HEIGHT
OVERALL
WIDTH W/O
STARTER
CENTER OF GRAVITY FOOTPRINT
EVAP
2
PASS
COND
2
PASS
EVAP COND
A A A B C X Y Z D E F G
2009 1809
134
(3404)
128
(3251)
134
(3404)
76
(1930)
42
(1067)
50
(1270)
37
(940)
16
(406)
113
(2870)
111
(2819)
42
(1067)
34
(864)
6 6
2012 1812
169
(4293)
163
(4140)
169
(4293)
76
(1930)
42
(1067)
68
(1727)
36
(914)
17
(432)
148
(3759)
145
(3683)
42
(1067)
34
(864)
6 6
2209 2009
134
(3404)
129
(3277)
134
(3404)
76
(1930)
42
(1067)
50
(1270)
36
(914)
17
(432)
113
(2870)
111
(2819)
42
(1067)
34
(864)
8 6
2212 2012
169
(4293)
164
(4166)
169
(4293)
76
(1930)
42
(1067)
68
(1727)
34
(864)
17
(432)
148
(3759)
145
(3683)
42
(1067)
34
(864)
8 6
2209 2209
134
(3404)
129
(3277)
134
(3404)
76
(1930)
42
(1067)
51
(1295)
35
(889)
17
(432)
113
(2870)
111
(2819)
42
(1067)
34
(864)
8 8
2212 2212
169
(4293)
164
(4166)
169
(4293)
76
(1930)
42
(1067)
68
(1727)
34
(864)
17
(432)
148
(3759)
145
(3683)
42
(1067)
34
(864)
8 8
2609 2209
134
(3404)
129
(3277)
134
(3404)
80
(2032)
46
(1168)
51
(1295)
37
(940)
20
(508)
113
(2870)
111
(2819)
46
(1168)
38
(965)
8 8
2612 2212
169
(4293)
164
(4166)
169
(4293)
80
(2032)
46
(1168)
69
(1753)
35
(889)
20
(508)
148
(3759)
145
(3683)
46
(1168)
38
(965)
8 8
2609 2609
134
(3404)
129
(3277)
134
(3404)
86
(2184)
48
(1219)
51
(1295)
40
(1016)
20
(508)
113
(2870)
111
(2819)
48
(1219)
40
(1016)
8 8
2612 2612
169
(4293)
164
(4166)
169
(4293)
86
(2184)
48
(1219)
69
(1753)
38
(965)
21
(533)
148
(3759)
145
(3683)
48
(1219)
40
(1016)
8 8
3012 2612
175
(4445)
167
(4242)
175
(4445)
90
(2286)
53
(1346)
67
(1702)
41
(1041)
21
(533)
148
(3759)
145
(3683)
53
(1646)
45
(1143)
10 8
Note: See notes on page 33.
