McQuay WDC User Manual

Product Manual PM WSC/WDC 33
Dimensions
Chillers
WSC 048/WSC 050, 80 to 150 tons
VESSEL CODE OVERALL LENGTH CONNECTIONS
1&3
PASS
2
PASS
HEAD CONN
BOTH ENDS
OVERALL
HEIGHT
OVERALL
WIDTH W/O
STARTER
CENTER OF GRAVITY FOOTPRINT
EVAP COND
A A A B C X Y Z D E F G
EVAP
2
PASS
COND
2
PASS
1809 1609
134
(3404)
128
(3251)
134
(3404)
71
(1803)
42
(1067)
55
(1397)
31
(787)
17
(432)
113
(2870)
111
(2819)
42
(1067)
34
(864)
6 5
1812 1612
169
(4293)
163
(4140)
169
(4293)
71
(1803)
42
(1067)
72
(1829)
30
(762)
16
(406)
148
(3759)
145
(3683)
42
(1067)
34
(864)
6 5
2009 1609
134
(3404)
128
(3251)
134
(3404)
71
(1803)
42
(1067)
55
(1397)
31
(787)
16
(406)
113
(2870)
111
(2819)
42
(1067)
34
(864)
6 5
2012 1612
169
(4293)
163
(4140)
169
(4293)
71
(1803)
42
(1067)
72
(1829)
30
(762)
16
(406)
148
(3759)
145
(3683)
42
(1067)
34
(864)
6 5
2009 1809
134
(3404)
128
(3251)
134
(3404)
71
(1803)
42
(1067)
55
(1397)
31
(787)
17
(432)
113
(2870)
111
(2819)
42
(1067)
34
(864)
6 6
2012 1812
169
(4293)
163
(4140)
169
(4293)
71
(1803)
42
(1067)
73
(1854)
30
(762)
17
(432)
148
(3759)
145
(3683)
42
(1067)
34
(864)
6 6
2209 2009
134
(3404)
129
(3277)
134
(3404)
71
(1803)
42
(1067)
55
(1397)
30
(762)
17
(432)
113
(2870)
111
(2819)
42
(1067)
34
(864)
8 6
2212 2012
169
(4293)
164
(4166)
169
(4293)
71
(1803)
42
(1067)
73
(1854)
29
(737)
17
(432)
148
(3759)
145
(3683)
42
(1067)
34
(864)
8 6
Notes:
1. Dimensions in inches (mm).
2. See Physical Data and Weights section for component and unit weights.
3. Allow three feet of service access on all four sides.
4. Allow the length of the tubes plus two feet on one end for tube removal. The last two numbers in the vessel code are the tube length in
feet.
5. Mounting holes are 1 1/8 in. (2.9 cm) diameter.
6. Approximate thickness of waffle pad when compressed: ¼ in. (.63 cm).
