Product Manual PM WSC/WDC 63
Specifications
SECTION 15XXX
CENTRIFUGAL CHILLERS
SINGLE COMPRESSOR
PART 1 — GENERAL
1.1 SUMMARY
Section includes design, performance criteria, refrigerants, controls, and installation requirements for water-
cooled centrifugal chillers.
1.2 REFERENCES
Comply with the following codes and standards
ARI 550/590 NEC
ANSI/ASHRAE 15 OSHA as adopted by the State
ASME Section VIII
1.3 SUBMITTALS
Submittals shall include the following:
A. Dimensioned plan and elevation view drawings, including motor starter cabinet, required
clearances, and location of all field piping and electrical connections.
B. Summaries of all auxiliary utility requirements such as: electricity, water, air, etc. Summary shall
indicate quality and quantity of each required utility.
C. Diagram of control system indicating points for field interface and field connection. Diagram
shall fully depict field and factory wiring.
D. Manufacturer’s certified performance data at full load plus IPLV or NPLV.
E Before shipment, submit a certification of satisfactory completion of factory run test signed
by a company officer. The test shall be performed on an ARI Certified test stand and
conducted according to ARI Standard 550.
F Installation and Operating Manuals.
1.4 QUALITY ASSURANCE
A. Qualifications: Equipment manufacturer must specialize in the manufacture of the products
specified and have five years experience with the equipment and refrigerant offered.
B. Regulatory Requirements: Comply with the codes and standards in Section 1.2.
C. Chiller manufacturer plant shall be ISO 9002 Registered.
1.5 DELIVERY AND HANDLING
A. Chillers shall be delivered to the job site completely assembled and charged with refrigerant
and oil.
B. Comply with the manufacturer’s instructions for rigging and transporting units. Leave
protective covers in place until installation.
