Product Manual PM WSC/WDC 61
Options and Accessories
Vessels
Marine water boxes
Provides tube access for inspection, cleaning, and removal without dismantling water piping.
Flanges (victaulic standard)
ANSI raised face flanges on either the evaporator or condenser. Mating flanges are by others.
0.028 (evaporator) or 0.035 in. tube wall thickness
For applications with aggressive water conditions requiring thicker tube walls.
Cupro-nickel or titanium tube material
For use with corrosive water conditions, only available with clad tube sheets.
Water side vessel construction of 300 psi (150 psi is standard)
For high pressure water systems, typically high-rise building construction.
Water flow or differential pressure switches
A proof of flow device is mandatory in the water system. They can be field supplied, mounted and wired. This
option provides them as a factory mounted and wired option.
Double insulation, 1 ½ inch, on evaporator, suction piping, and motor barrel
For high humidity locations and ice making applications.
No Insulation
This option for cases where insulation will be applied in the field. Chiller and suction line are not insulated.
Electrical
Optional starters for factory or field mounting
See details in the Motor Starter section of this manual.
NEMA 4 watertight enclosure
For use where there is a possibility of water intrusion into the control panel.
NEMA 12 Dust tight enclosure
For use in dusty areas.
Controls
English or Metric Display
Either English or metric units for operator ease of use.
Modem for remote monitoring
Includes the modem required for remote monitoring one or more units. Requires Monitor software.
Monitor software
Required for installation in a PC to complete remote monitoring capability.
Chiller System Controller
Details described in the Control Section of this manual.
