44 Product Manual PM WSC/WDC
Weights
Max. Unit Weight Without
Starter
Max. Unit Weight With Starter
Unit
Evaporator /
Condenser
Size
Certified
Drawing
Number
Shipping
lbs. (kg)
Operating
lbs. (kg)
Shipping
lbs. (kg)
Operating
lbs. (kg)
WSC050
1809 / 1609
WSC 050
5771 (2618)
6168 (2798)
6972 (3162)
7368 (3342)
WSC050
1812 / 1612
WSC 050
6504 (2950)
7004 (3177)
7704 (3495)
8204 (3721)
WSC050
2009 / 1609
WSC 050
6130 (2781)
6591 (2990)
7330 (3326)
7791 (3534)
WSC050
2012 / 1612
WSC 050
6933 (3145)
7510 (3407)
8133 (3689)
8711 (3951)
WSC050
2009 / 1809
WSC 050
6395 (2901)
6932 (3144)
7595 (3445)
8132 (3689)
WSC050
2012 / 1812
WSC 050
7267 (3296)
7938 (3601)
8467 (3841)
9138 (4145)
WSC050
2209 / 2009
WSC 050
7038 (3192)
7760 (3520)
8238 (3737)
8960 (4064)
WSC050
2212 / 2012
WSC 050
8077 (3664)
8972 (4070)
9277 (4208)
10172 (4614)
WSC063
2009 / 1809
WSC 063/087
8412(3816)
8949 (4059)
9612 (4360)
10149 (4604)
WSC063
2012 / 1812
WSC 063/087
9284 (4211)
9955 (4516)
10484 (4756)
11155 (5060)
WSC063
2209 / 2009
WSC 063/087
9119 (4136)
9841 (4464)
10319 (4681)
11040 (5008)
WSC063
2212 / 2012
WSC 063/087
10182 (4619)
11077 (5025)
11382 (5163)
12277 (5569)
WSC063
2209 / 2209
WSC 063/087
9416 (4271)
10235 (4643)
10616 (4815)
11435 (5187)
WSC063
2212 / 2212
WSC 063/087
10557 (4789)
11570 (5248)
11757 (5333)
12770 (5792)
WSC063
2609 / 2209
WSC 063/087
10248 (4648)
11258 (5107)
11448 (5193)
12458 (5651)
WSC063
2612 / 2212
WSC 063/087
11577 (5251)
12517 (5678)
12777 (5796)
14017 (6358)
WSC063
2609 / 2609
WSC 063/087
10984 (4982)
12228 (5547)
12184 (5527)
13428 (6091)
WSC063
2612 / 2612
WSC 063/087
12494 (5667)
14020 (6359)
13394 (6076)
15220 (6904)
WSC063
3012 / 2612
WSC 063/087
13903 (6306)
15569 (7062)
15103 (6851)
16769 (7606)
WSC079
2209 / 2209
WSC 063/087
10140 (4600)
10959 (4971)
11340 (5144)
12159 (5515)
WSC079
2212 / 2212
WSC 063/087
11281 (5117)
12294 (5577)
12481 (5661)
13494 (6121)
WSC079
2609 / 2209
WSC 063/087
10980 (4981)
11990 (5439)
12180 (5525)
13190 (5983)
WSC079
2612 / 2212
WSC 063/087
12309 (5592)
13548 (6145)
13509 (6128)
14749 (6690)
WSC079
2609 / 2609
WSC 063/087
11716 (5314)
12960 (5879)
12916 (5859)
14160 (6423)
WSC079
2612 / 2612
WSC 063/087
13226 (5999)
14752 (6692)
14426 (6544)
15952 (7236)
WSC079
3012 / 2612
WSC 063/087
14635 (6638)
16301 (7394)
15835 (7183)
17501 (7938)
WSC079
3012 / 3012
WSC 063/087
16119 (7312)
18061 (8192)
17319 (7856)
19261 (8737)
WSC079
3612 / 3012
WSC 063/087
18340 (8319)
20807 (9438)
19540 (8863)
22007 (9982)
WSC087
2609 / 2209
WSC 063/087
10980 (4981)
11990 (5439)
12180 (5525)
13190 (5983)
WSC087
2612 / 2212
WSC 063/087
12309 (5583)
13549 (6146)
13509 (6128)
14749 (6690)
WSC087
2609 / 2609
WSC 063/087
11716 (5314)
12960 (5879)
12916 (5859)
14160 (6423)
WSC087
2612 / 2612
WSC 063/087
13226 (5999)
14752 (6692)
14426 (6544)
15592 (7073)
WSC087
3009 / 2609
WSC 063/087
12892 (5848)
14246 (6462)
14092 (6392)
15446 (7006)
WSC087
3012 / 2612
WSC 063/087
14635 (6638)
16301 (7394)
15835 (7183)
17501 (7938)
WSC087
3009 / 3009
WSC 063/087
14076 (6385)
15644 (7096)
15276 (6929)
16844 (7640)
WSC087
3012 / 3012
WSC 063/087
16118 (7311)
18060 (8192)
17318 (7855)
19260 (8736)
WSC087
3609 / 3009
WSC 063/087
15913 (7218)
17929 (8133)
17113 (7762)
19129 (8677)
WSC087
3612 / 3012
WSC 063/087
18339 (8319)
20806 (9438)
19539 (8863)
22006 (9982)
WSC087
3612 / 3612
WSC 063/087
20584 (9337)
23799 (10795)
21784 (9881)
24999 (11340)
WSC100
3012 / 3012
WSC 100/126
19397 (8798)
21339 (9679)
20597 (9343)
22539 (10224)
WSC100
3612 / 3012
WSC 100/126
21578 (9788)
24045 (10907)
22778 (10332)
25245 (11451)
WSC100
3612 / 3612
WSC 100/126
23826 (10807)
27041 (12266)
25026 (11352)
28241 (12810)
WSC100
4212 / 3612
WSC 100/126
26457 (12001)
30260 (13726)
27657 (13545)
31460 (14270)
WSC100
4212 / 4212
WSC 100/126
29298 (13290)
34024 (15433)
30498 (13834)
35224 (15978)
WSC100
4812 / 4212
WSC 100/126
32024 (14526)
37623 (17066)
33224 (15070)
38823 (17610)
WSC126
3612 / 3012
WSC 100/126
21680 (9834)
24147 (10953)
22880 (10378)
25347 (11497)
WSC126
3612 / 3612
WSC 100/126
23928 (10854)
27143 (12312)
25128 (11398)
28343 (12856)
WSC126
4212 / 3612
WSC 100/126
26457 (12001)
30260 (13726)
27657 (12545)
31460 (14270)
WSC126
4212 / 4212
WSC 100/126
29298 (13290)
34024 (15433)
30498 (13834)
35224 (15978)
WSC126
4812 / 4212
WSC 100/126
32024 (14526)
37623 (17066)
33224 (15070)
38823 (17610)
WSC126
4812 / 4812
WSC 100/126
35016 (15883)
41817 (18968)
36216 (16427)
43017 (19513)
