Product Manual PM WSC/WDC 45
Max. Unit Weight Without Starter Max. Unit Weight With Starter
Unit
Evaporator /
Condenser
Size
Certified
Drawing
Number
Shipping
lbs. (kg)
Operating
lbs. (kg)
Shipping
lbs. (kg)
Operating
lbs. (kg)
WDC050 1812 / 1612 F5182162 8861 (4019) 9564 (4338) 11261 (5108) 11964 (5427)
WDC050 1812 / 1812 F5182182 9217 (4181) 10018 (4544) 11617 (5269) 12418 (5633)
WDC050 1816 / 1816 F5186186 10468 (4748) 11268 (5111) 12868 (5837) 13668 (6200)
WDC050 2012 / 1812 F5202182 9671 (4387) 10534 (4778) 12071 (5475) 12934 (5867)
WDC050 2016 / 1816 F5206186 11024 (5000) 12110 (5493) 13424 (6089) 14510 (6582)
WDC050 2212 / 2212 F5222222 11123 (5045) 12403 (5626) 13523 (6134) 14803 (6715)
WDC050 2216 / 2216 F5226226 12874 (5840) 14485 (6470) 15274 (6928) 16885 (7659)
WDC050 2412 / 2212 F5242222 12348 (5601) 13836 (6276) 14748 (6690) 16236 (7365)
WDC050 2416 / 2216 F5246226 13957 (6331) 15820 (7176) 16357 (7419) 18220 (8264)
WDC050 2612 / 2212 F5262222 12836 (5822) 14428 (6544) 15236 (6911) 16828 (7633)
WDC050 2616 / 2216 F5266226 14642 (6642) 16643 (7549) 17042 (7730) 19043 (8638)
WDC063 2416 / 2416 F6246246 18673 (8470) 20422 (9263) 21407 (9710) 23156 (10503)
WDC063 2416 / 2616 F6246266 19365 (8784) 21294 (9577) 22099 (10024) 23848 (10817)
WDC063 2616 / 2416 F6266246 19282 (8746) 21207 (9639) 22016 (9986) 23763 (10779)
WDC063 2616 / 2616 F6266266 20025 (9083) 22091 (9939) 22759 (10323) 24646 (11179)
WDC063 3016 / 3016 F6306306 23545 (10680) 26405 (11830) 26279 (11920) 28815 (13070)
WDC079 3016 / 3016 F7306306 25131 (11399) 27671 (12551) 27531 (12488) 30071 (13640)
WDC079 3616 / 3016 F7366306 28763 (13047) 32018 (14523) 31163 (14135) 34418 (15612)
WDC079 3616 / 3616 F7366366 32027 (14527) 36115 (16382) 34427 (15616) 38515 (17470)
WDC087 3016 / 3016 F8306306 26157 (11865) 28697 (13017) 28891 (13105) 31431 (14257)
WDC087 3616 / 3016 F8366306 29789 (13512) 33044 (14989) 32523 (14752) 35778 (15322)
WDC087 3616 / 3616 F8366366 33053 (14993) 37141 (16847) 35787 (16233) 39875 (18087)
WDC100 3616 / 3616 F0366366 41816 (18967) 46513 (21098) See Note See Note
WDC100 4216 / 4216 F0426426 50470 (22893) 57463 (26065) See Note See Note
WDC100 4816 / 4816 F0486486 59185 (26846) 68996 (31296) See Note See Note
WDC100 4220 / 4220 F0420420 54802 (24858) 63248 (28689) 57202 (25946) 65648 (29777)
WDC100 4820 / 4820 F0480480 65964 (29921) 77698 (35243) 68364 (31009) 80098 (36332)
WDC126 3616 / 3616 F0366366 41816 (18967) 46513 (21098) See Note See Note
WDC126 4216 / 4216 F0426426 50470 (22893) 57463 (26065) See Note See Note
WDC126 4816 / 4816 F0486486 59185 (26846) 68996 (31296) See Note See Note
WDC126 4220 / 4220 F2420420 54802 (24858) 63248 (28689) 57202 (25946) 65648 (29777)
WDC126 4224 / 4224 F2424424 62519 (28358) 72345 (32815) 64919 (29447) 74745 (33904)
WDC126 4820 / 4820 F2480480 65964 (29921) 77698 (35243) 68364 (31009) 80098 (36332)
WDC126 4824 / 4824 F2484484 75831 (34396) 89410 (40556) 78231 (35485) 91810 (41644)
Note: Unit not available with factory mounted starters.
