UNIT 3
PARTS LIST
Pos. Code NR Description
Rev. - - Sept. 2014
1 4032.456 UPPER BODY
2 4033.263 UPPER BODY MOBILE
3 4032.385 CHIMNEY
4 4032.465 INLET GRILL
5 4032.498 MOTOR
6 4033.019 FAN
7 4032.518 CENTRAL AIR FLAP
8 4104.170 CLIP NUT
9 4111.056 PROTECTION CABLE
10 4032.716 MOTOR FLANGE SUPPORT
11 4032.462 AIR FLAP
12 4160.646 PROTECTION CABLE
13 4111.241 ELASTIC PLATE
14 4032.480 HANDLE FRAME
15 4260.100 TANK CAP
16 4290.083 TANK FILTER
17 4100.632 DRAIN PLUG
18 4032.476 FOOT FRAME
19 4101.151 PROTECTION CABLE
20 4032.536 POWER CORD HOOK
21 4110.978 WHEEL
22 4111.480 WHEEL PLUG
23 4111.072 WHEEL HOLDER
24 4032.478 AXLE
25 4033.243 FUEL TANK
26 4032.466 ELECTR. COMPONENTS DRAWER PANEL
27 4032.470 LATERAL PANEL
28 4032.468 REAR PANEL
29 4033.264 LOWER BODY
30 4033.190 COMBUSTION CHAMBER
31 4033.223 OUTLET CONE
32 4031.068 CONN. STRAIGHT 1/4"
33 4031.067 PIPE CONNECTION 1/4"
34 4031.062 FUEL PIPE PUMP-TANK
35 4031.063 FUEL PIPE TANK-FILTER
36 4031.061 FUEL PIPE FILTER-PUMP
37 4033.090 FILTER CARTIDGE 3/8"
38 4111.116 OR KIT FILTER
39 4031.494 FILTER CARTIDGE
40 4032.437 FILTER SUPPORT
41 4031.064 DOUBLE SCREW
43 4160.646 PROTECTION CABLE
44 4033.257 PLASTIC BOX
45 4033.343 HT CABLE
46 4033.344 POWER CORD TRANSFORMER HT
47 4111.897 TRANSFORMER HT
48 4033.249 CONTROL BASE
49 4033.318 CONTROL BOX
50 4160.639 POP RIVET 4 WAY
51 4031.514 RELAY
52 4033.529 FUSE
53 4033.528 FUSE HOLDER
54 4033.248 FRONTAL CONTROLS PANEL
MODEL BV290 - 120 V / 60 Hz
