UNIT 4 PARTS LIST
Pos. Code NR Description
Rev. - - Sept. 2014
55 4033.254 PANEL LABEL
56 4100.656 LOCKNUT
57 4150.528 STRAIN RELIEF BUSHING
58 4032.502 POWER CORD UL
59 4162.467 THERMOSTAT CAP
60 4161.400 CONNECTION PLUG
61 4160.647 THERMOSTAT SOCKET 90°
62 4260.105 FUEL GAUGE
63 4165.204 ROCKER SWITCH
64 4033.251 BOARD BUTTON CAP
65 4033.505 TERMINAL BOX
66 4033.506 TERMINAL BOX CLOSING
71 4111.081 COUPLING
72 4033.357 PUMP
73 4161.501 CONN. STRAIGHT 1/8"
74 4033.198 ELBOW 1/8"
75 4033.186 OIL SUPPLY PIPE
76 4033.345 PUMP POWER CORD
77 4033.246 PHOTOCELL
80 4033.059 BURNER FLANGE
81 4031.030 NOZZLE
82 4033.071 TURBO DISC
83 4032.454 M6 NUT
84 4032.453 AIR REGOLATION FLAP
87 4111.826 ELECTRODE
88 4033.361 THERMOSTAT BRACKET
89 4033.368 THERMOSTAT BULB CLIP
90 4033.358 THERMOSTAT BULB BRACKET
91 4033.356 SAFETY AUTOMATIC RESET THERMOSTAT
92 4033.362 CLIP FOR WIRE AUTOMATIC THERMOSTAT
POS. Code NR Description
Rev. - - Sept. 2014
5
4032.498
MOTOR
38
4111.116
OR KIT FILTER
39
4031.494
FILTER CARTIDGE
45
4033.343
HT CABLE
47
4111.897
TRANSFORMER HT
49
4033.318
CONTROL BOX
51
4031.514
RELAY
52
4033.529
FUSE
59
4162.467
THERMOSTAT CAP
71
4111.081
COUPLING
72
4033.357
PUMP
76
4033.345
PUMP POWER CORD
77
4033.246
PHOTOCELL
81
4031.030
NOZZLE
87
4111.826
ELECTRODE
91
4033.356
SAFETY AUTOMATIC RESET THERMOSTAT
ESP00324
RECOMMENDED SPARE PARTS
MODEL BV290 - 120 V / 60 Hz
