Starter Time-out
Indicator / Check
Engine Light
When this amber light is illuminated, the starter circuit is temporarily disabled. The starter
circuit times out if the starter is run continuously for 15 seconds without the engine
starting. The starter functions resets after 30 seconds.
When blinking, functions as an Engine ECU Fault Code indicator.
6
Emergency Stop
Switch
Press the EMERGENCY STOP switch at any time to stop all machine functions.
Turn switch clockwise to reset.
7
Water & Fuel
Light
Indicates if water has contaminated fuel.
8
Platform Rotate
Switch
Press and hold the Function Enable Switch (#15), then move this switch left to rotate the
platform clockwise.
Press and hold the Function Enable Switch (#15), then move this switch right to rotate the
platform counterclockwise.
9
Platform Level
Switch
Press and hold the Function Enable Switch (#15), then move this switch left to rotate the
platform clockwise.
Press and hold the Function Enable Switch (#15), then move this switch right to rotate the
platform counterclockwise.
10
Overload
Indicator Light
Light ON indicates too much weight on the platform.
An audible alarm will sound and all machine function will stop.
Remove weight from the platform to restore function and continue.
11
Tilt Indicator
Light
This light illuminates and an alarm sounds when the machine is not level. Follow the
instructions on page 23 to safely lower the platform.
12
Boom Extend/
Retract
Press and hold the Function Enable Switch (#15), then move this switch right to extend
the boom.
Press and hold the Function Enable Switch (#15), then move this switch left to retract the
boom.
13 Boom Lift/Lower
Press and hold the Function Enable Switch (#15), then move this switch up to lift the
boom.
Press and hold the Function Enable Switch (#15), then move this switch down to lower the
boom.
14 Turntable Rotate
Press and hold the Function Enable Switch (#15), then move this switch left to rotate the
turntable clockwise.
Press and hold the Function Enable Switch (#15), then move this switch right to rotate the
turntable counterclockwise.
15
Function Enable
Switch
Press and hold this switch to enable boom, turntable and platform operations.
Press down to operate the controls at slow speed.
Press up to operate the controls at higher speed.
16 Jib Lift/Lower
Press and hold the Function Enable Switch (#15), then move this switch up to lift the jib.
Press and hold the Function Enable Switch (#15), then move this switch down to lower the
jib.
17 Circuit Breaker Trips when there is excessive electrical load. Push to reset.
18
Auxiliary Power
Switch
If normal power fails, press and hold while using boom retract and boom lower functions.
